Why a temporal field
Many datasets carry a clock. Counts of a species are taken year after year, disease cases arrive month by month, a sensor logs a reading every hour. The quantity you care about is usually a covariate effect: does abundance rise with temperature, does risk fall with vaccination coverage. The clock sits in the background, and the background moves.
When the background moves smoothly and you ignore it, the covariate pays for the omission. Suppose abundance drifts upward over a decade for reasons you never measured, and your covariate also happens to trend upward over the same decade. A model with no time term will read the shared drift as covariate signal and report a slope that is too steep. The trend and the covariate are confounded through time. This is the temporal twin of spatial confounding, and the fix has the same shape: give the model a flexible function of time, let it soak up the smooth background, and read the covariate effect off what remains.
The confounding has a mechanism worth stating plainly. A regression slope is the covariation of the response and the covariate divided by the variance of the covariate. If both response and covariate share a slow drift, part of that covariation comes from the drift rather than from any direct link between them. The slope cannot tell the two sources apart on its own. A flexible time term gives it a way to: anything that varies smoothly across time can be carried by the curve, so the slope is left to explain only the part of the covariate that wiggles faster than the background can follow. The price is that a covariate which is itself very smooth in time becomes hard to disentangle, and its interval widens to admit the doubt. That widening is honest. A model with no time term would have reported a narrow interval around the wrong value.
The choice of how flexible to make the time term is the modelling decision. Too stiff and the curve cannot absorb the background, leaving the bias in the slope. Too loose and it chases noise, stealing signal that belonged to the covariate. A random walk handles this by learning its own flexibility from the data through a single smoothing parameter, rather than asking you to pick the number of knots or the bandwidth by hand. The data decide how much the trend is allowed to bend.
tulpa offers that flexible function as a first-order random walk. You
declare it once, hand it to tulpa() through the
temporal= argument, and the engine threads it through the
same nested-Laplace machinery that integrates a spatial field. The
covariate slope comes back with a marginalized standard error, the trend
itself can be pulled out time point by time point, and the smoothing
strength is summarised by a single hyperparameter. This vignette walks
the full path: write down the model, simulate a known trend, fit, check
the recovery, read the uncertainty honestly, predict, and compare
against a model with no time term.
A note on scope before we start. The front-door route through
tulpa() carries the first- and second-order random walks
and the autoregressive process, temporal_rw1(),
temporal_rw2(), and temporal_ar1(). A panel
(per-group) trend runs through the same door, and a temporal field can
sit beside an areal (ICAR, BYM2, CAR) spatial field. Pairing a panel
trend with a spatial field, or a temporal field with a continuous (GP,
NNGP, HSGP) or SPDE spatial field, raises a clean error and points you
at the direct fitters. The main example below uses
temporal_rw1(); the closing section runs the others.
The model
Write the linear predictor for observation as
where is the time index of observation and is a vector of one effect per time point. The covariate part is the usual fixed-effect structure. The new piece is , and the model is its prior.
The prior on encodes a belief about time: nearby time points are alike. Rather than impose a parametric shape such as a line or a polynomial, a random walk imposes only local smoothness and lets the global shape emerge. This is why it suits a background you cannot name. The claim is modest: the trend does not jump, and beyond that it can take whatever shape the data support, quadratic or sinusoidal or neither.
A first-order random walk says that consecutive time points should be close. Formally, the increments are independent and Gaussian,
with precision . Large pins neighbouring time points together and forces a nearly flat trend; small lets the walk wander. The joint prior on is a Gaussian Markov random field with precision matrix , where is the structure matrix
and all other entries zero. Reading row by row reveals what it is: the penalty on ties it to its two chain neighbours, exactly the intrinsic conditional-autoregressive (ICAR) penalty you would write for a spatial field on a graph whose graph happens to be a line. An RW1 is an ICAR on a chain. That identity is what lets tulpa reuse one integration path for both: the chain adjacency (time neighbours and ) produces the precision above, and the nested-Laplace driver integrates it.
The conditional form of the prior makes the smoothing concrete. Conditional on its neighbours, an interior time point has mean equal to the average of the two adjacent points,
Each point is pulled toward the midpoint of its neighbours, and the strength of the pull is set by . This is the same conditional structure an ICAR field imposes on a spatial graph, with two neighbours instead of however many a map region happens to have. The endpoints, having one neighbour each, are pulled toward that single neighbour with twice the conditional variance, which is why the corner entries of are rather than .
Why an intrinsic prior rather than a proper one. The random walk fixes how the trend changes, not where it sits, and that is exactly the property you want from a confounding sponge: the field should be free to take whatever level the data imply without competing with the covariates for it. The cost is the rank deficiency, handled below by a constraint. The benefit is that the prior says nothing about the absolute level of the trend, only its shape, which is the honest position when the background is something you never measured.
The matrix has rank . The walk fixes increments, not levels, so the whole trend can slide up or down by a constant without changing any increment. That constant is the unidentified direction, and it collides with the intercept . tulpa resolves it with a sum-to-zero constraint on , which has a consequence we return to when reading the intercept: under an intrinsic field the intercept absorbs the free level and its standard error sits near the prior width by design.
One switch changes the geometry. With cyclic = TRUE the
chain closes into a ring, so time
becomes a neighbour of time
and the increment
joins the prior. A ring is the
right structure for phase-wrapped data where the last bin really does
sit next to the first: month of year, hour of day, compass bearing. The
default is the open chain, which suits a calendar year sequence where
2010 and 2030 are not neighbours.
The difference shows up at the boundary. On an open chain the endpoints are weakly tied, each to a single neighbour, so the trend can swing freely at the ends where the data are thinnest. On a ring every point has two neighbours, the seam included, so a December estimate borrows strength from January and the trend joins up without a discontinuity at the wrap. For seasonal data fitted on an open chain, a spurious jump between the last and first bin is a common artefact; the ring removes it by construction. The rank deficiency stays at one in both cases, so the same single constraint identifies the level either way.
Simulating data
To check that the fit recovers what it should, simulate with a trend you choose. Lay down time points and a smooth seasonal-looking trend, a single sine wave centred at zero so it does not fight the intercept.
T_pts <- 30L
trend <- as.numeric(scale(sin(2 * pi * seq_len(T_pts) / T_pts)))Scaling to mean zero and unit variance keeps the trend on a comparable footing with the covariate effect, so neither dwarfs the other in the linear predictor. Now draw observations, assign each to a time point, give each a covariate , and build a binary response. The true intercept is , the true slope is , and each observation picks up the trend value at its time point.
set.seed(42)
n <- 900L
time <- sample(seq_len(T_pts), n, replace = TRUE)
x <- rnorm(n)
eta <- -0.2 + 0.9 * x + trend[time]
y <- rbinom(n, 1, plogis(eta))
df <- data.frame(y = y, x = x, time = time)The time column holds integer time indices, but any
orderable variable works. validate_temporal() sorts the
unique values and maps them to a chain in that order, so calendar years,
dates, or ordered factor levels all land on the same
index internally. The trend enters every observation that shares a time
point, which is what gives the random walk enough replication per node
to be informed.
A few details in the setup are deliberate. The trend is centred, so
it carries shape but no level, which keeps it from quarrelling with the
intercept and mirrors the sum-to-zero constraint the model will apply.
The covariate is drawn independently of time here, so this simulation
tests recovery rather than confounding correction; the trend and the
slope describe genuinely separate features of the data and a good fit
should return both. The thirty time points with nine hundred
observations leave each time point about thirty observations on average,
comfortably enough to inform each
and the smoothing precision above them. If you wanted to study
confounding directly, you would make
correlate with trend[time] and watch the no-trend slope
inflate while the temporal model holds near
.
The single sine wave is a convenient truth because it is smooth, bounded, and has no preferred level, so the centred trend the model recovers should overlay it cleanly. The walk knows nothing of sine waves; it learns only that neighbours are close, and the sine wave is a fair test of whether that local smoothness is enough to reconstruct a global shape from noisy binary data.
Fitting
Declare the temporal structure with temporal_rw1(),
naming the time column, and pass the spec through
temporal=. The spec carries the time variable itself, the
same way a continuous spatial spec carries its coordinates, so there is
no temporal(col) term in the formula.
tspec <- temporal_rw1("time")
fit <- tulpa(y ~ x, data = df, family = "binomial",
temporal = tspec, mode = "auto")
coef(fit)
#> (Intercept) x
#> -0.2132393 0.8881760The slope lands near the true . The intercept reads near zero with a very wide interval, the sum-to-zero constraint at work, covered below. How was the fit routed?
c(backend = fit$backend, tier = fit$inference_tier)
#> backend tier
#> "nested_laplace" "2"
fit$selection_reason
#> [1] "temporal rw1 field; nested-Laplace integration"mode = "auto" recognised the temporal field, turned the
RW1 into its chain ICAR block, and sent it to the nested-Laplace backend
(Tier 2). That backend puts a grid over the smoothing precision
,
runs an inner Laplace fit at each grid point, and integrates over the
grid. The conditional mode = "laplace" path is not wired
for temporal fields yet, so every temporal selection routes to the
nested integrator.
The two-layer structure is worth picturing. The inner layer is an
ordinary Laplace fit: hold
fixed, find the mode of the fixed effects and the trend together, and
read the curvature there. The outer layer treats
as the unknown it is, places a grid of candidate values across a
sensible range, runs the inner fit at each, and weights the results by
how well each
explains the data. Nothing is fixed at a single best smoothness. The
reported slope and its uncertainty are an average across the grid, so a
fit that is genuinely unsure how smooth the trend should be will say so
through a wider slope interval rather than a falsely confident one.
summary() gives the fixed-effect table with marginalized
standard errors and credible bounds.
summary(fit)
#> estimate std.error 2.5% 97.5%
#> (Intercept) -0.2132393 0.10488702 -0.4227211 -0.01157154
#> x 0.8881760 0.08880567 0.7320449 1.08015672confint() returns the same bounds as a matrix.
confint(fit)
#> 2.5% 97.5%
#> (Intercept) -0.4227211 -0.01157154
#> x 0.7320449 1.08015672
#> attr(,"skew_applied")
#> (Intercept) x
#> TRUE TRUE
#> attr(,"interval_source")
#> [1] "skew_map_cell"
#> attr(,"interval_declined")
#> [1] "skew_correct: gamma_3 is retained at the MAP cell only, so the mixture components carry no per-cell skew to compose; the coefficients it declines keep the read they would have had"
#> attr(,"retained_mass")
#> [1] 1Extracting the temporal trend
The fixed-effect accessors report
,
but the trend
is the reason you added the field. A nested fit carries the per-grid
posterior modes in $modes, a matrix with one row per grid
point and one column per latent coordinate, ordered as
[fixed effects, field]. It also carries the grid
$weights. The grid-marginalized value of the field at time
is the weight-averaged mode in the column for that time point.
w <- fit$weights / sum(fit$weights)
nf <- fit$n_fixed
phi_hat <- vapply(seq_len(T_pts),
function(u) sum(w * fit$modes[, nf + u]),
numeric(1))
round(head(phi_hat), 3)
#> [1] 0.247 0.604 0.822 0.976 1.259 1.373The offset nf + u skips the nf fixed-effect
columns and lands on the field column for time
.
The weighted sum integrates over the smoothing precision rather than
fixing it at a point, which is the whole reason for the grid. This
recipe is identical for a spatial field; only the meaning of the index
changes.
The column ordering is the key to reading $modes. Each
row is one grid point’s joint posterior mode for the latent vector, laid
out as the fixed effects first and the field after, so column
nf + u is always time point
regardless of how many grid points the integrator chose. Averaging down
the rows with the grid weights collapses the smoothing uncertainty into
a single trend value per time point. If you wanted a credible band on
the trend rather than a point, you would carry the per-grid curvature
for the field columns through the same law of total variance the fixed
effects use, combining within-grid variance and between-grid spread; the
point estimate above is enough for the recovery check this vignette
runs.
Checking the fit
A recovery check plots the estimated trend against the truth. Because the random walk is identified only up to an additive constant, centre both before comparing.
plot(seq_len(T_pts), trend - mean(trend), type = "l", lwd = 2,
xlab = "time point", ylab = "centred temporal effect")
lines(seq_len(T_pts), phi_hat - mean(phi_hat), col = "darkorange", lwd = 2)
legend("topright", c("truth", "estimate"),
col = c("black", "darkorange"), lwd = 2, bty = "n")
The estimate tracks the sine wave it was built from, smoothed a touch where the prior pulls neighbours together. The correlation between the two confirms it.
The smoothing precision
controls how tightly the walk hugs a straight line, and the fit reports
its posterior summary directly. $theta_mean is the
posterior mean of the field’s hyperparameter, with
$theta_ci_lo and $theta_ci_hi bounding it.
c(mean = fit$theta_mean,
lower = fit$theta_ci_lo,
upper = fit$theta_ci_hi)
#> mean lower.value upper.value
#> 8.687384 2.811919 21.330535A larger means a stiffer walk. Here the interval excludes the very large values that would flatten the trend to a line, so the data have spoken for some curvature, consistent with the sine wave underneath.
Reading the precision interval is a useful diagnostic in its own right. If the posterior for piled up against the upper edge of the grid, that would say the data prefer a trend so smooth it is nearly flat, a hint that the field is absorbing little and might be dropped. If it piled against the lower edge, the trend would be straining to wiggle as much as the grid allows, a hint that the prior is too restrictive or that something faster than a smooth trend is at work. An interval comfortably inside the grid, as here, says the smoothing strength is identified and the trend is doing real work without overfitting. The grid bounds themselves come from the spec, so a precision pinned at an edge is also a cue to widen them and refit.
Interpreting the fit
Two points deserve care when reading the table.
First, the standard error on the slope is marginalized. The nested
driver does not report the slope uncertainty at a single best
;
it folds the per-grid fixed-effect covariances together through the law
of total variance, so the interval already accounts for not knowing the
smoothing strength exactly. tulpa() keeps the per-grid
Hessians for this purpose. The practical reading is that the slope
interval is honest about the trend being estimated rather than
known.
The law of total variance is the right tool because the slope uncertainty has two sources. Within any single grid point the inner Laplace fit gives a covariance for the fixed effects, the curvature of the log-posterior at that . Across grid points the slope estimate itself moves, because a stiffer or looser trend leaves a slightly different residual for the covariate to explain. The total variance adds two pieces: the average of the within-grid covariances, plus the spread of the per-grid estimates. Both the conditional uncertainty and the smoothing uncertainty land in one interval. A naive fit that picked the single best and reported its covariance would capture only the first term and understate the interval, sometimes badly when the trend is hard to pin down. The coverage of the marginalized interval is tested at its nominal rate, so the ninety-five percent bounds mean what they say.
Second, the intercept. Under an intrinsic field the level of the trend is not separately identified from , so the sum-to-zero constraint hands the intercept a near-flat posterior and its standard error sits at roughly the prior width.
summary(fit)["(Intercept)", c("estimate", "std.error")]
#> estimate std.error
#> (Intercept) -0.2132393 0.104887That large standard error is a feature of the parameterisation, not a sign the fit failed. Interpret slopes, which are identified and marginalized; do not read the intercept as an estimate of the overall level. If you need a level, it lives in the trend , which you extract and centre as shown above.
The reason traces straight back to the intrinsic prior. The random walk constrains increments, so the data inform the shape of and the height of taken together, but not the split between them. tulpa pins to sum to zero and lets float, which is one valid way to break the tie, and under that choice the intercept inherits the unidentified level. A different software might pin the intercept and let the trend float; the slopes, which depend on neither convention, come out the same. The lesson is to anchor interpretation on quantities that do not depend on how the tie was broken. Slopes qualify. Differences in the trend between two time points qualify too, since the shared level cancels. The bare intercept stands apart, tied to a convention rather than to the data.
Prediction
predict() gives the fixed-effect prediction at new
covariate values, with the field held at its population average. On the
link scale the intercept’s wide posterior flows straight into the
standard error, so a raw link-scale band is dominated by that
unidentified level rather than by covariate uncertainty.
nd <- data.frame(x = seq(-2, 2, length.out = 50))
pr <- predict(fit, newdata = nd, type = "link", se.fit = TRUE)
round(head(pr, 2), 3)
#> fit se.fit lower upper
#> 1 -1.990 0.210 -2.401 -1.578
#> 2 -1.917 0.204 -2.316 -1.518The informative quantity is how the prediction changes with , which is the slope and its tight interval, not the absolute height of the line. To show the covariate effect cleanly, plot the link-scale prediction centred at its own mean, so the intercept’s free level drops out and the slope’s uncertainty is what remains.
ctr <- pr$fit - mean(pr$fit)
plot(nd$x, ctr, type = "l", lwd = 2,
xlab = "x", ylab = "centred linear predictor")
band <- (pr$upper - pr$lower) / 2
polygon(c(nd$x, rev(nd$x)),
c(ctr - band, rev(ctr + band)),
col = adjustcolor("steelblue", 0.25), border = NA)
lines(nd$x, ctr, lwd = 2)
The band is narrow because the slope is well identified, even though
the line’s absolute position is not. Centring is the right move
precisely because the quantity of interest is a contrast: the difference
in linear predictor between two covariate values, which the slope
controls and the intercept cancels out of. The raw se.fit
is not wrong, it is answering a different question, namely how uncertain
the absolute height of the line is, and under an intrinsic field that
height is barely identified.
predict() holds the temporal field at its population
average. What you see is the covariate effect with the trend
marginalised out, not a forecast at a particular time. To predict at a
specific time point, add that time’s
value from the extracted trend to the linear predictor before applying
the inverse link, and set the intercept to whatever level you want to
anchor on. The engine’s population-level predict()
deliberately stays on the marginal trend, so the default answer is the
covariate relationship rather than a time-specific one.
Comparing against no temporal field
Does the trend earn its place? Fit the same model without a time term
and compare evidence. On a Laplace-tier fit logLik()
returns the approximate log marginal likelihood, the quantity to compare
across specifications.
m_nt <- tulpa(y ~ x, data = df, family = "binomial", mode = "laplace")
as.numeric(logLik(m_nt))
#> [1] -576.4314A nested fit integrates over a grid of
,
so its $log_marginal is a vector with one entry per grid
point. The model evidence is the log of the grid-summed marginal
likelihood, a log-sum-exp over that vector.
lse <- function(v) { m <- max(v); m + log(sum(exp(v - m))) }
evidence_temporal <- lse(fit$log_marginal)
c(no_temporal = as.numeric(logLik(m_nt)), temporal = evidence_temporal)
#> no_temporal temporal
#> -576.4314 -514.8424The temporal model carries substantially higher evidence, matching
the fact that a trend really was in the data.
compare_models() ranks fits by a shared criterion, reading
each one’s logLik().
cmp <- compare_models(no_temporal = m_nt,
temporal = fit,
criterion = "loglik")
cmp
#> model n_params logLik
#> 1 no_temporal 2 -576.4314
#> 2 temporal 2 -514.8424On the nested temporal fit logLik() returns the
integrated evidence, the log-sum-exp of $log_marginal
computed above, so compare_models() carries one row per
model and reproduces the manual comparison alongside the non-temporal
logLik().
A word on what this comparison settles. The marginal likelihood already integrates over the walk and its smoothing precision, so it charges the temporal model for the extra flexibility it brought, and a higher value therefore means the trend paid for itself once that charge was levied. The gain in fit outweighed the added complexity. That is the property that makes the marginal likelihood the right yardstick for nested specifications, where one model is the other with a structural piece added. The raw maximised likelihood cannot do this job, since it always rises with more parameters and would crown the temporal model even when the curve was only chasing noise. Predictive scores such as WAIC and LOO answer a related but separate question about out-of-sample accuracy; they need a pointwise log-likelihood the base engine does not carry, so they live in the model packages built on it.
A second family
The same call shape works for a Gaussian response; only
family and the dispersion phi change. Reuse
the trend and slope, swap the binary draw for a Gaussian one.
set.seed(7)
yg <- -0.2 + 0.9 * x + trend[time] + rnorm(n, sd = 0.5)
dfg <- data.frame(y = yg, x = x, time = time)
fitg <- tulpa(y ~ x, data = dfg, family = "gaussian",
temporal = tspec, mode = "auto", phi = 0.5)
coef(fitg)["x"]
#> x
#> 0.9227363The slope again recovers near
,
and the same field-extraction recipe lifts the trend out of
fitg$modes. For the Gaussian family the dispersion
phi is the residual variance, conditioned on rather than
estimated on this path, so the value you pass should reflect the noise
you expect; here it matches the sd = 0.5 the data were
drawn with. The mechanics are otherwise unchanged. The same chain ICAR
block, the same grid over
,
the same marginalized slope. Only the inner likelihood differs, which is
the point of routing every family through one integrator.
Practical guidance
A handful of rules of thumb for everyday use.
Give the walk enough time points. An RW1 needs at least 2 points to be defined, but a trend with fewer than about 8 to 10 time points has little room to bend, and the smoothing precision is then weakly informed. Below that, consider treating time as a small set of fixed effects instead. Replication matters as much as count: many observations per time point inform each far better than one observation each.
Pick the smoothness to match the trend you expect. RW1 penalises first differences, so it favours piecewise-flat trends and can look a little blocky. RW2 penalises second differences and favours trends that are locally straight, giving a smoother curve. If the underlying process is a gentle long-term drift, RW2 is usually the better prior; for trends that genuinely change level in steps, RW1 fits the shape. RW2 needs at least 3 time points.
Use
cyclic = TRUEfor phase-wrapped data. Month of year, hour of day, and compass bearing all close on themselves, so December sits next to January and the ring’s wrap-around increment lets the trend join up across the seam. Leave itFALSEfor an open calendar sequence whose endpoints are not neighbours.Read slopes, not the intercept. Under the intrinsic RW1 the intercept’s standard error sits near the prior width because the trend level is not separately identified. The covariate slopes are identified and their intervals are marginalized over . If you need the overall level, read it from the extracted, centred trend.
Skip the field when time carries no shared signal. If observations are not clustered in time, or the response has no plausible smooth temporal component, a random walk only adds parameters and softens the slope. Fit with and without the term and compare evidence, as above; let the data say whether the trend earns its place.
What is wired, and what is not yet
The front door through tulpa() carries all three
temporal priors. temporal_rw2() penalizes second
differences for a smoother trend than RW1:
fit_rw2 <- tulpa(y ~ x, data = df, family = "binomial",
temporal = temporal_rw2("time"), mode = "auto")
coef(fit_rw2)
#> (Intercept) x
#> -0.2127041 0.8958525temporal_ar1() is a stationary, full-rank alternative
with an estimated correlation parameter rather than an intrinsic walk.
Panel trends through group_var= fit a separate walk per
group sharing one hyperparameter, and a temporal field combined with an
areal
(icar/car/bym2/car_proper)
spatial field forms an additive space-time joint prior over the
[spatial, temporal] block stack:
# AR1 temporal trend
tulpa(y ~ x, data = df, family = "binomial",
temporal = temporal_ar1("time"), mode = "auto")
# Panel: one walk per site, shared smoothness
tulpa(y ~ x, data = panel_df, family = "binomial",
temporal = temporal_rw1("time", group_var = "site"), mode = "auto")
# Additive space-time
tulpa(y ~ x + spatial(region), data = st_df, family = "binomial",
spatial = list(type = "icar", adjacency = W),
temporal = temporal_rw1("time"), mode = "auto")Still off the front door: a panel temporal field alongside a spatial
or latent() block, and continuous
(gp/nngp/hsgp) or SPDE
space-time. Those report a clear error rather than dropping the term;
the dedicated cpp_nested_laplace_st_* kernels exist for
later wiring.
See also
?temporal_rw1: constructor reference.The spatial vignette: the same nested-Laplace path on an areal ICAR field.
The
tgmrf()vignette: building a custom GMRF latent block, including a periodic AR(1), end to end.The inference-modes vignette: what the Tier-2 nested-Laplace guarantee means.
