Validating calibration: simulation-based calibration

library(tulpa)

What the instrument reads

diagnostics() scores one fit. It asks whether the machinery that produced that posterior behaved: whether the chains mixed, whether the outer grid covered the hyperparameter posterior, whether the inner Gaussian was a reasonable shape for the latent conditional. Those are verdicts on the procedure at one data set.

Calibration is a different question, and no single fit can answer it. An inference algorithm is calibrated when its posteriors are self-consistent across the whole generative model: simulate a truth, simulate data at that truth, fit, and the truth should land at a uniformly distributed position inside the posterior it produced. Repeat that many times and those positions have a distribution you can test.

The usual way to check this is coverage: count how often a 95% interval contains the truth. That reads one point of the marginal CDF, or two if you also run a 50% interval. It cannot say whether a posterior is biased, over-dispersed, under-dispersed or asymmetric, and it is weak enough that two genuinely different reads of the same fit can score identically on it. sbc() reads the whole CDF.

The measurement is the probability integral transform. For a scored quantity whose true value is theta_0 and whose reported posterior CDF is F, take u = F(theta_0). Under exact inference u is exactly Uniform(0, 1), so the entire empirical CDF of the u values across simulations is the test statistic (Talts et al. 2018).

A model to validate

A balanced Gaussian random-intercept model: six regions of four observations each, an intercept and one covariate, a random intercept per region whose standard deviation sigma is drawn from a seven-point grid.

The design is small on purpose. The sigma posterior then spreads across four or five of the seven grid cells, which is the regime where the outer-grid mixture posterior for a fixed effect is farthest from the Gaussian matching its first two moments.

GRID <- exp(seq(log(0.2), log(1.5), length.out = 7))
PHI  <- 0.7
BETA <- c(-0.2, 0.7)

simulate_one <- function(seed) {
  set.seed(seed)
  sigma  <- GRID[sample.int(length(GRID), 1L)]
  region <- rep(seq_len(6L), each = 4L)
  X      <- cbind(1, rnorm(24L))
  u      <- rnorm(6L, 0, sigma)
  list(y      = as.numeric(X %*% BETA) + u[region] + rnorm(24L, 0, PHI),
       X      = X,
       region = region,
       theta  = c(beta1 = BETA[1], beta2 = BETA[2], sigma = sigma))
}

fit_one <- function(d, diagnose = FALSE) {
  tulpa_nested_laplace(
    y = d$y, n_trials = rep(1L, length(d$y)), X = d$X,
    prior = list(list(type = "iid", obs_idx = d$region,
                      n_units = max(d$region), sigma_grid = GRID)),
    family = "gaussian", phi = PHI,
    control = list(n_threads = 1L, keep_grid_hessians = TRUE,
                   auto_recenter = FALSE, progress = FALSE,
                   diagnose_k = diagnose, diagnose_skew = diagnose))
}

simulate_one() has to be a pure function of its seed, and it returns theta, the named vector of true values the PIT is taken against. auto_recenter = FALSE is not a speed knob: the argument that the sigma PIT is uniform needs the fitted grid to be the same seven points the truth was drawn from, and a recentred grid breaks it.

The single-fit reliability diagnostics are off inside the loop. Each one costs its own batch of inner solves per fit, and the last section is where they get read, on one fit rather than two hundred.

Reporting a fit in a shape `sbc()` can read

A fitter callback returns a named list of arms, each a named list over scored quantities, each entry one of the predictive shapes in ?sbc_predictive. Everything downstream dispatches on the shape’s kind tag, so a backend reporting something new is one shape rather than a parallel scorer.

Two of them cover a nested-Laplace fit. What the outer grid defines for a fixed effect is a Gaussian mixture over the cells, and tulpa_posterior_draws() realizes it: each draw picks a cell by its weight, then samples that cell’s inner Gaussian. coef() and vcov() report that same mixture’s first two moments, so building an sbc_normal() from them is the collapsed read of the identical posterior. For the hyperparameter the grid defines a distribution on a finite support, which is sbc_discrete().

arms <- function(d) {
  fit <- fit_one(d)
  m   <- coef(fit)
  se  <- sqrt(diag(vcov(fit)))
  D   <- tulpa_posterior_draws(fit, n = 2000)
  w   <- fit$weights / sum(fit$weights)

  list(
    mixture = list(
      beta1 = sbc_draws(D[, 1]),
      beta2 = sbc_draws(D[, 2]),
      sigma = sbc_discrete(as.numeric(fit$theta_grid), w)),
    collapsed = list(
      beta1 = sbc_normal(m[1], se[1]),
      beta2 = sbc_normal(m[2], se[2])),
    narrow = list(
      beta1 = sbc_normal(m[1], se[1] / 1.25),
      beta2 = sbc_normal(m[2], se[2] / 1.25)))
}

Every arm reads off one solve per seed, so an arm-to-arm difference carries no fit-to-fit noise. narrow is a deliberately mis-scaled posterior, the same moments with the standard deviation divided by 1.25. A calibration harness that cannot fail is worth nothing, so the run below has to put it outside the band.

The prior-predictive experiment

res <- sbc("prior_predictive",
           simulator  = simulate_one,
           fitter     = arms,
           n_sim      = 200L,
           flat_prior = c("beta1", "beta2"))
res
#> Simulation-based calibration -- prior_predictive, 200 simulations
#>   band: 0.95 simultaneous (equal local levels, exact crossing probability)
#>   CRPS: proper posterior score
#>   proper prior: verified over 10 probed simulations; flat prior asserted for beta1, beta2
#>
#>        arm quantity   n     ks inside p_unif inside_folded p_folded     crps
#>    mixture    beta1 200 0.0426   TRUE  0.746          TRUE   0.5120 0.173650
#>    mixture    beta2 200 0.0667   TRUE  0.202         FALSE   0.0379 0.095863
#>    mixture    sigma 200 0.0785   TRUE  0.285          TRUE   0.0986 0.106190
#>  collapsed    beta1 200 0.0541   TRUE  0.568          TRUE   0.1180 0.173570
#>  collapsed    beta2 200 0.0713   TRUE  0.397          TRUE   0.0915 0.095918
#>     narrow    beta1 200 0.0679   TRUE  0.335          TRUE   0.3150 0.173820
#>     narrow    beta2 200 0.0522   TRUE  0.569          TRUE   0.5030 0.095476
#>  crps_se
#>  0.01030
#>  0.00442
#>  0.00698
#>  0.01010
#>  0.00439
#>  0.01110
#>  0.00496
#>
#> 7 of 7 (arm, quantity) reads inside the band; outside the band: mixture/beta2.

flat_prior is a guard doing its job. Ordinary SBC draws the truth from the prior, so an improper prior has nothing to draw from, and the nested-Laplace door puts no prior on the fixed effects. sbc() probes the simulator, sees that beta1 and beta2 do not move across simulations, and refuses to score them unless the caller names them. Naming them asserts that their flat prior leaves the PIT uniform by a structural argument; the assertion is checked in both directions and travels on the result in res$premises.

Three reads of the same PIT sample

ks and p_unif read the raw PIT ECDF. inside_folded and p_folded read 2 |u - 1/2|, which is also uniform under correct inference. The fold is where a symmetric error shows: a posterior that is too narrow pushes PIT mass towards both ends at once, which cancels in the raw ECDF and accumulates in the folded one. crps is the continuous ranked probability score, closed form for a Gaussian mixture, so the nested tier’s own posterior is scored with no Monte Carlo.

inside is the verdict against a simultaneous band. A pointwise binomial band is not one: at n = 100, holding each order statistic inside its own 95% interval holds all of them together only 44.71% of the time. The band here is calibrated by bisection against the exact crossing probability of the uniform order statistics, so an ECDF excursion anywhere along the curve is a 0.05-level event.

Discrete quantities are randomized within their atom, u = F(theta^-) + V P(theta), so sigma on its seven-point grid and a continuous coefficient share one uniform reference and one band. Reading a rank against a continuous uniform is the classic silent SBC bug, and it is not something you can opt into here.

The proper score, paired

summary(baseline = ) pairs the CRPS seed by seed against one arm.

summary(res, baseline = "mixture")
#> Simulation-based calibration -- prior_predictive, 200 simulations
#>   CRPS: proper posterior score
#>
#>        arm quantity   n     ks inside p_unif inside_folded p_folded     crps
#>    mixture    beta1 200 0.0426   TRUE  0.746          TRUE   0.5120 0.173650
#>    mixture    beta2 200 0.0667   TRUE  0.202         FALSE   0.0379 0.095863
#>    mixture    sigma 200 0.0785   TRUE  0.285          TRUE   0.0986 0.106190
#>  collapsed    beta1 200 0.0541   TRUE  0.568          TRUE   0.1180 0.173570
#>  collapsed    beta2 200 0.0713   TRUE  0.397          TRUE   0.0915 0.095918
#>     narrow    beta1 200 0.0679   TRUE  0.335          TRUE   0.3150 0.173820
#>     narrow    beta2 200 0.0522   TRUE  0.569          TRUE   0.5030 0.095476
#>  crps_se
#>  0.01030
#>  0.00442
#>  0.00698
#>  0.01010
#>  0.00439
#>  0.01110
#>  0.00496
#>
#> Paired CRPS against arm 'mixture' (negative delta = better)
#>  quantity       arm   n      delta     t worse_frac   p_sign
#>     beta1 collapsed 200 -7.729e-05 -0.16      0.620 0.000845
#>     beta1    narrow 200  1.715e-04  0.18      0.375 0.000499
#>     beta2 collapsed 200  5.578e-05  0.27      0.505 0.944000
#>     beta2    narrow 200 -3.865e-04 -0.61      0.385 0.001400
#>   delta with its t is the proper-score verdict; p_sign is a more
#>   powerful detector of a difference but is not itself proper.

delta with its t is the proper-score verdict; a negative delta is the arm scoring better. p_sign is more powerful at detecting that two arms differ at all, but the sign test is not a proper score, so it cannot rank them.

Expect the mixture and collapsed arms to score close together. They carry the same first two moments, and the CRPS integrates the whole squared CDF difference, which those moments dominate. Where they separate is on the ECDF reads above, which is why both instruments are worth running.

The CRPS is a proper posterior score here only because the truth is drawn afresh each simulation. Hold the truth fixed across seeds and the CRPS-optimal forecast is a point mass at it, so a sharper wrong posterior wins. That is enforced rather than documented: a fixed-truth sweep is not offered as an experiment, and summary(baseline = ) refuses to rank one.

The picture

plot(res, arm = c("mixture", "narrow"), quantity = "beta2")

PIT ECDF difference from uniform against the simultaneous band

plot(res, arm = c("mixture", "narrow"), quantity = "beta2", folded = TRUE)

Folded PIT ECDF difference from uniform against the simultaneous band

The plot draws the ECDF difference from uniform, so a calibrated read is a flat line at zero inside the band. The under-dispersed arm bows away from it, and the bow is larger folded than raw.

Calibration conditional on an observed data set

The experiment above averages over the prior. A user fitting their own data asks something narrower: is the inference reliable in the posterior geometry this data set produces. The prior average can miss a defect confined to a small region of parameter space, and it can flag one the observed data rules out.

experiment = "posterior" answers the narrow question (Sailynoja et al. 2026, Algorithm 2). Draw theta' from pi(theta | y_obs), simulate a replicate at theta', and take the PIT under the augmented posterior pi(theta | y, y_obs). That is ordinary SBC with pi(theta | y_obs) in the role of the prior, so the same band, the same folded read and the same proper score all carry over, and it needs no proper prior at all.

It takes six callbacks.

d_obs <- simulate_one(99L)

model <- list(
  data_obs = d_obs,

  fit = function(data) fit_one(data),

  draw_theta = function(fit, seed) {
    set.seed(seed)
    b <- tulpa_posterior_draws(fit, n = 1L)
    k <- attr(b, "cells")[1]
    c(beta1 = unname(b[1, 1]), beta2 = unname(b[1, 2]),
      sigma = as.numeric(fit$theta_grid)[k])
  },

  simulate = function(theta, seed) {
    set.seed(seed)
    region <- rep(seq_len(6L), each = 4L)
    X      <- cbind(1, rnorm(24L))
    u      <- rnorm(6L, 0, theta[["sigma"]])
    list(y = as.numeric(X %*% theta[c("beta1", "beta2")]) +
           u[region] + rnorm(24L, 0, PHI),
         X = X, region = region)
  },

  pool = function(obs, rep) list(
    y      = c(obs$y, rep$y),
    X      = rbind(obs$X, rep$X),
    region = as.integer(c(obs$region, rep$region + max(obs$region)))),

  arms = function(fit, data) {
    m  <- coef(fit)
    se <- sqrt(diag(vcov(fit)))
    D  <- tulpa_posterior_draws(fit, n = 2000)
    list(
      mixture = list(
        beta1 = sbc_draws(D[, 1]),
        beta2 = sbc_draws(D[, 2]),
        sigma = sbc_discrete(as.numeric(fit$theta_grid),
                             fit$weights / sum(fit$weights))),
      narrow = list(
        beta1 = sbc_normal(m[1], se[1] / 1.25),
        beta2 = sbc_normal(m[2], se[2] / 1.25)))
  },

  group_ids = function(data) data$region)

pres <- sbc("posterior", model = model, n_sim = 200L)
pres
#> Simulation-based calibration -- posterior, 200 simulations
#>   band: 0.95 simultaneous (equal local levels, exact crossing probability)
#>   CRPS: proper posterior score (updating prior = posterior at y_obs)
#>   pooling: verified; fresh groups: verified (disjoint group labels)
#>
#>      arm quantity   n     ks inside  p_unif inside_folded p_folded     crps
#>  mixture    beta1 200 0.0474   TRUE 0.53500          TRUE 0.167000 0.086533
#>  mixture    beta2 200 0.0513   TRUE 0.77900          TRUE 0.470000 0.069730
#>  mixture    sigma 200 0.0729   TRUE 0.52100          TRUE 0.431000 0.060628
#>   narrow    beta1 200 0.0612  FALSE 0.01730         FALSE 0.001610 0.086355
#>   narrow    beta2 200 0.0612  FALSE 0.00395         FALSE 0.000447 0.069845
#>  crps_se
#>  0.00485
#>  0.00371
#>  0.00406
#>  0.00526
#>  0.00408
#>
#> 3 of 5 (arm, quantity) reads inside the band; outside the band: narrow/beta1, narrow/beta2.

The driver hands draw_theta and simulate different seeds, so set.seed(seed) at the top of each is the correct fixture. Giving both the same seed makes the replicate’s noise a function of the truth, which is not p(y | theta'), and it shows up as a non-uniform PIT with nothing wrong in the inference under test.

Two premises, and what checks them

Each premise silently turns the construction into something that is not SBC, so each has a guard, and each guard’s conclusion travels on the result.

str(pres$premises)
#> List of 2
#>  $ pooling     : chr "verified"
#>  $ fresh_groups: chr "verified (disjoint group labels)"

The augmented posterior conditions on both data sets. Fitting the replicate alone is ordinary SBC under a hand-made prior. sbc() refuses a pool() returning no more than the replicate, or no more than the observed data.

The replicate is conditionally independent of y_obs given theta. The nested tier integrates the random effects out, so theta carries no per-group value, and a replicate drawn on the same regions couples the two data sets through the group effects theta does not describe. simulate() above draws six fresh regions and pool() offsets their labels past the observed ones. Supply group_ids and the observable half of that is verified, the labels being disjoint. Omit it and the result records the premise as unverified rather than assumed. The other half, that the replicate’s group effects came from the prior rather than conditionally on y_obs, is not visible from outside the callback and is not claimed.

A third requirement is a property of draw_theta rather than a guard. theta' has to be a joint draw from pi(theta | y_obs). Sampling beta from tulpa_posterior_draws() and sigma independently from the grid weights gives the right two marginals and the wrong joint, and the sigma read leaves the band when you do it. Reading attr(b, "cells") takes the coefficient and the hyperparameter from the same cell, which is what makes the draw joint.

Where this sits beside the single-fit band

diagnostics() on a nested fit reports the outer Pareto-k-hat, the inner skewness estimate gamma_3 and the inner importance k-hat, combined into one reliability band. That band runs on the fit you already have; sbc() costs a few hundred fits. So the band is what you read routinely, and this is what you reach for when the answer has to hold up.

The cheap one is not a compressed version of the expensive one, and the two disagree in both directions. Measured over fifteen configurations at 1000 simulations (dev_notes/issue339/): a Poisson configuration carrying an outer k-hat of 0.196 with both inner scores in the good band, the cleanest verdict the band can give, fails calibration at p = 2.3e-13 on its intercept. A binomial configuration carrying an outer k-hat of 1.413, well past the 0.7 escalation threshold, passes at p = 0.17.

So read the shipped band as a screen. A rejection from sbc() is the strong statement: on that same measurement the false-positive rate is 0.0117 against a nominal 0.05, and power reaches 80% at roughly a 10% dispersion error or a 0.14-SD location bias, which makes a pass the weaker one.

diagnostics() reads both at once when you hand it the calibration result.

fit <- fit_one(d_obs, diagnose = TRUE)
diagnostics(fit, sbc = res)
#> Nested-Laplace WHOLE-FIT reliability (i.i.d. draws)
#>   two layers: the outer hyperparameter-grid integration, and the inner Gaussian Laplace on the latent field
#>   outer PSIS pareto_k = 0.790 (unreliable); IS-ESS = 63.1
#>   outer grid quadrature ESS = 4.30 of 7 cells (max weight 0.309)
#>   note: outer grid holds material weight on a boundary node of b1.sigma (lower): that axis truncates its own marginal there, whether or not its mode sits on the node -- widen it and refit to see what is outside
#>   note: outer grid axis maximal at its own boundary on b1.sigma:lower (not moved: auto_recenter_disabled): the span does not contain that axis's mode, so its marginal is a truncated tail at any spacing -- widen or pin that axis and refit
#>   note: outer grid resolution could not be scored on b1.sigma (mode_at_edge): 0 of 1 axes carry a cell-width / posterior-SD ratio, so the grid is not established as resolved on the rest -- an axis reading `mode_at_edge` is one whose nodes do not contain its own posterior mode, which no spacing statement can be made about
#>   note: outer grid does not contain its own posterior mode on b1.sigma:lower: that axis's extreme node carries the modal mass, so its reported bound is an extrapolation off the end of the design -- widen the axis rather than adding nodes inside it
#>   inner Laplace max |gamma_3| = 0.000 (good), scored 2/2 latents
#>   inner Laplace importance pareto_k = 0.275 (good), min IS efficiency 1.0000, scored 2/2 latents
#>     the importance weights are uniform on every probed index: the inner
#>     Gaussian reproduces the conditional posterior over the sampled region,
#>     so the shape above describes no correction and is not banded
#>   whole-fit verdict: scoped: outer (hyperparameter) integration flagged
#>   calibration (SBC, prior_predictive): outside the band: mixture/beta2
#>   per-parameter columns: none.
#>     the fit carries no posterior draws, so the per-parameter mean / sd / ESS / rhat columns are empty; tulpa_posterior_draws(fit) samples the retained outer-grid mixture if a sample is wanted

References

Talts, S., Betancourt, M., Simpson, D., Vehtari, A. and Gelman, A. (2018). Validating Bayesian inference algorithms with simulation-based calibration. arXiv:1804.06788.

Sailynoja, T., Schmitt, M., Buerkner, P.-C. and Vehtari, A. (2026). Posterior SBC: simulation-based calibration checking conditional on data. Statistics and Computing 36, 78. doi:10.1007/s11222-026-10825-9.

Gneiting, T. and Raftery, A. E. (2007). Strictly proper scoring rules, prediction, and estimation. Journal of the American Statistical Association 102, 359-378.
