Spatial fields in tulpa

library(tulpa)

Why a spatial field

Regions that sit next to each other tend to look alike. Two adjacent counties share weather, soil, road networks, and the people who move between them, so their disease counts, yields, or survey rates carry a similar unmeasured signal. A regression that ignores this treats each region as an independent draw, and that assumption fails in two ways at once.

The first failure is in the residuals. Neighbouring regions leave correlated leftovers, the model’s effective sample size is smaller than the row count suggests, and the standard errors come out too small. You can see this in any map of model residuals: when nearby regions share the sign of their leftover, an inference procedure that assumes independence counts each of those regions as fresh information when, statistically, they are partly the same observation seen twice. Confidence intervals shrink below their nominal width, and a slope that is really uncertain gets reported as sharp.

The second failure is in the coefficients themselves. When a covariate is itself spatially patterned, say elevation or median income, it competes with the unmeasured regional signal for the same variance. The fitted slope then absorbs part of that signal and drifts away from the effect you meant to estimate. This is the spatial face of confounding by an omitted variable: the covariate and the missing regional driver vary together across space, and a model with no place to put the regional driver has no choice but to load it onto the covariate. The bias stays hidden in plain sight. The slope looks plausible, the fit looks clean, and the number is wrong.

Both failures share one cause. The model has nowhere to absorb the part of the response that depends on where an observation sits rather than on its covariates. A spatial field is the place. You add one random effect per region, tie neighbouring effects together so the field stays smooth, and let it soak up the regional signal the covariates do not explain. The slope is then read against a background that already accounts for location. The standard errors widen to their honest size because the random effect, not the covariate, now carries the spatial autocorrelation.

The smoothing is the subtle part. A free random effect per region with no ties between neighbours would absorb the signal, but it would also absorb the covariate effect you are trying to measure, because with enough free parameters it can mimic almost anything. The neighbour ties are what keep the surface smooth and let the covariate keep its own variance. How strong those ties should be is a parameter in its own right, and a fit that fixes it by hand is making a choice the data could make better. tulpa builds the field from an adjacency matrix, integrates the smoothing strength over a grid rather than fixing it, and reports a standard error that carries the field’s own uncertainty into the fixed effects.

This vignette stays on the areal path, where regions are discrete units joined by an adjacency graph. We simulate a known field on a ring of regions, fit it, pull the field back out per region, check that it matches the truth, look at how the smoothing precision is recovered, and compare a spatial fit against a non-spatial one. Continuous fields, where the signal lives on raw coordinates, get a short note at the end with pointers to their own vignettes.

The model

Write the response for observation $i$ in region $r_i$ through a linear predictor on the link scale:

$g(\mu_i) \;=\; \beta_0 + x_i^\top \beta + \phi_{r_i},$

where $\beta_0$ is the intercept, $\beta$ the covariate slopes, and $\phi_{r}$ the spatial effect for region $r$ . The field $\phi$ carries the regional signal; everything spatially structured that $x$ misses lands there.

The intrinsic conditional autoregressive (ICAR) prior ties the field to the adjacency graph. Each region’s effect is centred on the mean of its neighbours:

$\phi_r \mid \phi_{-r} \;\sim\; \mathcal{N}\!\left( \frac{1}{n_r}\sum_{s \sim r} \phi_s,\;\; \frac{1}{\tau\, n_r}\right),$

with $s \sim r$ meaning $s$ is a neighbour of $r$ , $n_r$ the number of neighbours, and $\tau$ a precision that sets how tightly the field is smoothed. The conditional form above is convenient for intuition, since it says each region pulls toward its neighbours’ average. The joint distribution it implies is a Gaussian Markov random field with precision matrix

$Q \;=\; \tau\,(D - W),$

where $W$ is the adjacency matrix and $D$ the diagonal of neighbour counts. The off-diagonal entries of $Q$ are nonzero only between neighbours, which is what makes $Q$ sparse and the model cheap to work with even on thousands of regions. That sparsity is the Markov property of the random effect written as a matrix, not a numerical convenience tacked on afterward. A region is conditionally independent of every non-neighbour given its neighbours, and that conditional independence is exactly a zero in $Q$ .

The matrix $D - W$ is the graph Laplacian. Its smallest eigenvalue is zero, with the constant vector as eigenvector, so $Q$ is rank-deficient by one. The practical consequence is that the field is pinned only up to an additive constant: shifting every $\phi_r$ by the same amount does not change the joint density. The overall level is left for the intercept to identify, and the field carries only the contrasts between regions, the part that actually describes spatial pattern. This is what makes the ICAR an intrinsic prior, improper on its own but proper once the data and a sum-to-zero handling fix the level.

The precision $\tau$ sets the smoothing strength. A large $\tau$ inflates the penalty on neighbour differences, forces neighbours to agree, and flattens the field toward the constant. A small $\tau$ relaxes the penalty and lets each region drift toward an independent random effect. The value that fits the data is rarely known in advance, and choosing it wrong has a real cost: too much smoothing erases genuine pattern, too little lets it chase noise and steal variance from the covariates. Integrating $\tau$ rather than fixing it is the point of the nested path used below.

BYM2 splits the field into a spatially structured ICAR part and an unstructured per-region part:

$\phi_r \;=\; \frac{1}{\sqrt{\tau}}\left(\sqrt{\lambda}\,u_r^{\star} + \sqrt{1-\lambda}\,v_r\right),$

where $u^{\star}$ is a scaled ICAR field, $v$ an IID per-region effect, and $\lambda \in [0,1]$ a mixing parameter for the share of variance that is spatially structured. As $\lambda \to 1$ the field is pure ICAR; as $\lambda \to 0$ it collapses to independent noise. The ICAR component is scaled following Riebler et al. (2016) so that $\lambda$ reads on a comparable scale from one graph to the next, which a raw ICAR variance does not. Both icar and bym2 route through the same machinery in tulpa; the choice between them is about interpretation, and it comes back in the practical guidance below.

A proper CAR sits between the two. It keeps the single field of the ICAR but replaces the fixed unit autocorrelation with an estimated parameter $\rho$ , so the precision becomes $Q = \tau\,(D - \rho W)$ . With $\rho$ free in its valid range the field can range from near-independence at small $\rho$ to near-ICAR as $\rho$ approaches one, and the precision is proper rather than rank-deficient, which incidentally tames the intercept confounding. The cost is one more parameter to integrate and a field that no longer reduces to the clean graph Laplacian. For most smoothing tasks ICAR or BYM2 is the practical starting point, with proper CAR held in reserve for when the autocorrelation strength is itself a quantity of interest.

Simulating data

A simulation with a known field is the only honest way to check a spatial fit. Real data never reveal the truth, so a recovered field that merely looks reasonable proves nothing. Here we set the field by hand, generate the response from it, and ask the fit to find it again. The test has teeth: the response is binary, the data are spread thin across many regions, and the field carries structure no intercept can fake.

Put twenty-five regions on a ring, each adjacent to its two neighbours. The ring is the smallest graph that is connected, regular, and has an obvious smooth field on it. A regular graph keeps every region with the same neighbour count, so no region is privileged by the topology, and a ring’s single loop gives the field one clean wavelength to recover.

K <- 25
W <- matrix(0, K, K)
for (i in 1:K) {
  j <- if (i < K) i + 1 else 1
  W[i, j] <- W[j, i] <- 1
}

The true field is one smooth wave around the ring, centred and scaled so its values run from roughly $-1.5$ to $1.5$ . A wave is a fair test on two counts. It is smooth, so an ICAR prior that rewards agreement between neighbours should track it well rather than fight it. And it has real structure, a peak on one side of the ring and a trough on the other, that no single intercept can capture, so the random effect has to do genuine work. A pattern of pure noise would be the opposite test, one an ICAR prior is designed to smooth away, and recovering it would say little.

field_true <- as.numeric(scale(sin(2 * pi * (1:K) / K)))
beta0 <- -0.2
beta1 <-  0.8

Draw n observations, assign each to a region, and build a binomial response on the logit scale. The intercept is $-0.2$ , the covariate slope $0.8$ , and the region’s field value adds to the linear predictor.

n      <- 800
x      <- rnorm(n)
region <- sample(1:K, n, replace = TRUE)
eta    <- beta0 + beta1 * x + field_true[region]
y      <- rbinom(n, size = 1, prob = plogis(eta))
ds     <- data.frame(y = y, x = x, region = factor(region))

The slope we want back is beta1; the field we want back is field_true. Eight hundred observations spread across twenty-five regions average to thirty-two rows each, but the sampling is random, so several regions land with far fewer. Those thin regions are where neighbour borrowing earns its keep: a region with a handful of binary trials cannot estimate its own effect, yet its neighbours can lend it theirs, and the smoothing is the channel that lending flows through.

Fitting

An areal field needs two pieces that travel together. The spatial= argument carries the structure, a list with the field type and the adjacency matrix. A spatial(region) term in the formula names the column that maps each row to its region. Drop either piece and tulpa() stops with a message rather than guessing.

fit <- tulpa(y ~ x + spatial(region), data = ds, family = "binomial",
             spatial = list(type = "icar", adjacency = W),
             mode = "nested_laplace")
fit$backend
#> [1] "nested_laplace"

mode = "nested_laplace" runs the Tier-2 path that integrates the field’s precision $\tau$ over a grid rather than fixing it. The path lays a grid of $\tau$ values, runs an inner Laplace solve of the random effect and fixed coefficients at every value, weights each grid point by its marginal likelihood, and pools the answers. This integration turns a single guessed smoothing strength into a posterior over smoothing strengths, which is why the coefficient errors below inherit the field’s uncertainty instead of pretending $\tau$ is known exactly.

For a binomial areal field, mode = "auto" makes a different choice. It picks the Polya-Gamma Gibbs sampler, a Tier-1 exact fit that draws from the posterior directly and is the natural match for a binomial response. That sampler is correct and often what you want, but it does not expose the integration grid, so the per-region effects and the smoothing hyperparameter are not laid out on the returned object the way the nested path arranges them. This vignette requests nested_laplace explicitly so the marginalised field and $\tau$ summary are available to plot and check. For a routine binomial areal model where only the slopes matter, mode = "auto" is the lighter call.

The fixed effects come back from coef().

coef(fit)
#> (Intercept)           x
#>  -0.3184731   0.8181402

The slope lands near the simulated $0.8$ . With the regional wave absorbed into the field, the covariate reports its own effect rather than a blend of effect and location. summary() adds the posterior standard error and the 2.5% / 97.5% credible bounds.

These standard errors are grid-marginalised, and the distinction matters. At a single fixed $\tau$ the Laplace solve gives a within-point covariance, the uncertainty in the slope conditional on that smoothing strength. Such a conditional error understates the truth because it behaves as though $\tau$ were known. The law of total variance repairs this: the marginal variance of the slope equals the average within-point variance plus the spread of the within-point means across the grid. tulpa retains the per-grid covariance (control$keep_grid_hessians defaults to on for precisely this reason) and combines both terms, so the reported error absorbs the cost of not knowing how smooth the surface is.

summary(fit)
#>               estimate  std.error       2.5%       97.5%
#> (Intercept) -0.3184731 0.13111212 -0.5828865 -0.06893647
#> x            0.8181402 0.09488012  0.6512063  1.02312957

Extracting the field per region

The slopes are only half the story. Often the field itself is the quantity of interest, the smoothed map you wanted in the first place, and the nested fit carries it on the object. $modes is an n_grid by n_latent matrix. Each row is one grid point’s inner-Laplace mode, and the columns run [fixed effects, field], so the first n_fixed columns are the intercept and slopes and the rest are the per-region effects. $weights are the integration weights over the grid, one per row, and they sum to one after normalising.

The grid-marginalised value for region $u$ is the weighted average of its own column across grid points: take column n_fixed + u, weight each grid point’s entry by its integration weight, and sum. This is the same marginalisation the slopes get, applied to the latent field instead of the fixed effects.

w     <- fit$weights / sum(fit$weights)
nf    <- fit$n_fixed
field_hat <- vapply(seq_len(K), function(u) sum(w * fit$modes[, nf + u]),
                    numeric(1))
round(head(field_hat), 3)
#> [1] 0.272 0.375 0.804 0.776 1.495 1.495

That recipe is the same one the temporal path uses for a random-walk field, since an RW1 chain is an ICAR on a line: time $t$ neighbours $t-1$ and $t+1$ , the chain adjacency’s Laplacian is the RW1 precision, and the field-extraction step reads the same $modes columns. One marginalisation serves both areal maps and time series.

Checking the fit

Recovery means two things here: the field traces the truth, and the smoothing precision sits where the data put it.

Plot the fitted values against the simulated ones. The intrinsic prior identifies the field only up to an additive constant, so centre both sequences before comparing.

plot(field_true - mean(field_true),
     field_hat  - mean(field_hat),
     xlab = "true field (centred)", ylab = "estimated field (centred)",
     pch = 19, col = "steelblue")
abline(0, 1, lwd = 2, col = "grey40")

Estimated spatial field per region against the simulated truth, near the identity line

cor(field_true, field_hat)
#> [1] 0.9812883

The points fall along the identity line and the correlation is high. The fit has recovered the wave from binary data spread thin across twenty-five regions, which is exactly what neighbour borrowing buys. A region with only a few trials does not stand alone; its estimate is pulled toward the smooth curve its neighbours trace, and the binary noise that would swamp an isolated estimate averages out along the curve. The centring matters because the intrinsic prior fixes the effect only up to a constant, so the truth and the estimate can differ by an overall level even when their shapes match perfectly. Subtracting each mean removes that free constant and leaves the contrasts, which are what the model actually identifies.

The precision $\tau$ is summarised on the object. $theta_mean is the posterior mean over the grid, on the natural precision scale, and $theta_ci_lo / $theta_ci_hi give a credible interval.

c(tau_mean = fit$theta_mean,
  lo = fit$theta_ci_lo, hi = fit$theta_ci_hi)
#>  tau_mean  lo.value  hi.value
#>  4.991525  1.567037 12.004982

A larger $\tau$ would mean a stiffer penalty on neighbour differences and a flatter surface; in the limit of very large $\tau$ the effect collapses to a constant and the spatial structure vanishes. The interval here sits well away from that limit, so the data are telling you the pattern has real wiggle worth keeping. Reading $\tau$ alongside the recovered map is a useful habit. An apparently structured map whose $\tau$ interval drifts toward large values warns that the structure may be the prior talking rather than the data; a flat map with a small $\tau$ is the data declining to find any pattern at all.

Interpreting the fit

Two points govern how to read a nested areal fit.

The first is uncertainty. The slope’s standard error in summary() is not the conditional error you would get by fixing $\tau$ at one value. It is marginalised over the grid of $\tau$ values, so it already includes the cost of not knowing how smooth the field is. confint() returns the same bounds as a matrix, and vcov() the fixed-effect covariance.

confint(fit)
#>                   2.5%       97.5%
#> (Intercept) -0.5828865 -0.06893647
#> x            0.6512063  1.02312957
#> attr(,"skew_applied")
#> (Intercept)           x
#>        TRUE        TRUE
#> attr(,"interval_source")
#> [1] "skew_map_cell"
#> attr(,"interval_declined")
#> [1] "skew_correct: gamma_3 is retained at the MAP cell only, so the mixture components carry no per-cell skew to compose; the coefficients it declines keep the read they would have had"
#> attr(,"retained_mass")
#> [1] 1

The second point is the intercept, and it follows directly from the rank-deficiency of the ICAR precision. Under an intrinsic field the overall level of $\phi$ and the intercept $\beta_0$ are confounded: shifting every $\phi_r$ up by a constant and the intercept down by the same constant leaves the linear predictor, and therefore the likelihood, unchanged. The two parameters trade off along a flat ridge, and no amount of data can pin them both. tulpa handles this by letting the intercept float against a near-flat prior, which shows up as a very wide intercept standard error in the summary above. The slopes are unaffected, because a covariate’s effect does not live on that ridge. Read the slopes, which are identified, and treat the intercept as a nuisance level rather than a quantity to interpret.

summary(fit)["(Intercept)", "std.error"]
#> [1] 0.1311121

The wide value here is by design, not a fitting failure. A proper CAR or a BYM2 field with its IID part tamed will narrow it, at the cost of an extra estimated parameter. Whenever you report results from an intrinsic model, say so plainly: the intercept is a floating reference, the slopes are the inferential payload, and a reader who treats the intercept as an absolute baseline rate will be misled. This caveat travels with every disease-map or species-distribution table that smooths over an adjacency graph.

Prediction

predict() gives the fixed-effect prediction at new covariate values. The spatial field is held at its population level, so the result is the marginal covariate trend with the regional signal averaged out. This is the right default for a question like “what does the covariate do on average across the map”, as opposed to “what happens in region 7”, which needs that region’s field value added back. se.fit = TRUE adds the link-scale standard error and credible bounds, drawn from the same grid-marginalised fixed-effect covariance the summary uses.

nd <- data.frame(x = seq(-2.5, 2.5, length.out = 50))
pr <- predict(fit, newdata = nd, type = "link", se.fit = TRUE)
head(pr, 3)
#>         fit    se.fit     lower     upper
#> 1 -2.363824 0.2778939 -2.908486 -1.819162
#> 2 -2.280340 0.2693917 -2.808338 -1.752342
#> 3 -2.196856 0.2609716 -2.708351 -1.685361

Plot the trend on the link scale with its credible band.

plot(nd$x, pr$fit, type = "n", xlab = "x", ylab = "predicted logit")
polygon(c(nd$x, rev(nd$x)), c(pr$lower, rev(pr$upper)),
        col = adjustcolor("steelblue", 0.25), border = NA)
lines(nd$x, pr$fit, lwd = 2)

Predicted logit response across x with a 95 percent credible band

For a probability instead of a logit, pass type = "response"; the prediction and its bounds then pass through the inverse-logit and stay inside $[0, 1]$ . Region-specific predictions come from adding the extracted field_hat[r] to the link-scale fit for that region’s rows, then mapping through the link. The field value carries the region’s departure from the average, so a region in the wave’s peak predicts above the marginal trend and one in the trough below it, by exactly the field contrast you recovered earlier.

Comparing against a non-spatial fit

Does the field earn its place? A high correlation with a known truth says yes in simulation, but on real data there is no truth to check against. What you can still ask is whether the field improves the model enough to justify its parameters, and the marginal likelihood answers exactly that. It is the probability of the data with every latent quantity integrated out, so a model is not rewarded for the extra flexibility of a field unless that flexibility buys real fit. Compare the same mean structure with and without the field on this scale.

A nested fit reports its log marginal likelihood per grid point in $log_marginal, one value for each $\tau$ on the integration grid. The single integrated evidence is the log-sum-exp of that vector, which adds the per-grid evidences on the probability scale before taking logs again. The non-spatial Laplace fit has no grid and reports a scalar log marginal likelihood directly through logLik().

m0 <- tulpa(y ~ x, data = ds, family = "binomial", mode = "laplace")

lse  <- function(z) { m <- max(z); m + log(sum(exp(z - m))) }
ev_spatial    <- lse(fit$log_marginal)
ev_nonspatial <- as.numeric(logLik(m0))
c(nonspatial = ev_nonspatial, spatial = ev_spatial)
#> nonspatial    spatial
#>  -518.8611  -463.8058

ev_spatial - ev_nonspatial
#> [1] 55.05533

The spatial fit carries the higher evidence by a wide margin, matching how the data were built. The difference is the log Bayes factor for the field, and a value this large is decisive: the data are vastly more probable with a field than without one. The marginal likelihood is the right currency because it already integrates over the field and its precision, so adding the field is not rewarded for free. It has to pay for its parameters through the integration and still come out ahead, which guards against the overfitting that a raw goodness-of-fit comparison would invite.

compare_models() ranks fits by criterion = "loglik", reading each fit’s logLik(). On a nested fit logLik() returns the integrated evidence, the log-sum-exp of $log_marginal shown above, so compare_models() reports one row per model and the areal-versus-flat ranking matches the manual differencing. The same comparison runs for two spatial models, an ICAR against a BYM2 for instance, by taking the log-sum-exp of each fit’s $log_marginal and differencing.

Practical guidance

A few rules of thumb for areal fields, with the numbers that make them actionable.

At least 8 to 10 regions, ideally more. The precision $\tau$ is learned from how much neighbouring regions differ, and a handful of units leaves it barely informed. Below roughly eight regions, a fixed effect per region is usually the honest choice over a smoothed field, since with so few units there is little to gain from borrowing and the smoothing parameter is mostly prior. The field repays the extra machinery when you have dozens to thousands of regions, many of them thin.
Check the graph is connected. A field on a disconnected adjacency splits into independent pieces, each pinned to its own floating level, and the intercept can no longer anchor them jointly. The number of zero eigenvalues of the graph Laplacian diag(rowSums(W)) - W counts the connected components; more than one means the graph is split.
Read slopes, never the intercept, under ICAR. The intercept confounds with the field level and its standard error runs to the prior scale, on the order of 100 on the link scale, against slope errors three orders of magnitude smaller. That gap is expected and is the signature of the intrinsic ridge, not a convergence problem. If you need a clean intercept, move to a proper CAR or a BYM2 field, whose IID part breaks the exact confounding.
ICAR versus BYM2. Reach for icar when you want the simplest smooth field and do not need to separate structured from unstructured variation; it has one fewer parameter and a clean interpretation as pure smoothing. Reach for bym2 when you want an interpretable spatial fraction $\lambda$ , when some regional variation is plausibly independent noise rather than smooth signal, or when the Riebler scaling matters for comparing the field’s magnitude across maps with different graphs. In disease mapping BYM2 is the common default for exactly these reasons; for a quick smoothing pass ICAR is the lighter choice.
When a spatial field is the wrong tool. Three cases call for leaving it out. If the residuals from a non-spatial fit show no neighbour correlation, a field adds parameters and uncertainty for nothing, and the marginal-likelihood comparison above will report equal or lower evidence for the spatial model. If you have fewer than about eight regions, the smoothing parameter is too weakly informed to help. And if the units are not truly areal, raw points on a map rather than regions joined by borders, a continuous field fits the geometry better than an adjacency you would have to invent by binning the points into arbitrary cells.

Continuous fields

The areal path assumes the world comes pre-divided into regions with borders. Often it does not. Survey points, sensor locations, and trap sites sit on continuous coordinates, and the spatial signal is smooth in distance rather than tied to administrative units. When the signal lives on coordinates rather than discrete regions, tulpa carries three continuous fields. Each takes its coordinates in the spec, so there is no spatial(col) term and no adjacency to build:

spatial_gp(~ lon + lat) fits a nearest-neighbour Gaussian process (NNGP), an exact GP thinned to each point’s nearest neighbours so it scales to large data.
spatial_gp(~ lon + lat, approx = "hsgp") fits a Hilbert-space approximate GP, a sum of basis functions that is fast for moderate ranges.
spatial_spde(~ lon + lat, data) fits a Matern field through the SPDE representation on a mesh, routed to the dedicated spde backend.

gp_spec <- spatial_gp(~ lon + lat)
gp_spec$type
#> [1] "gp"

The call shape mirrors the areal path: pass the spec through spatial=, choose a mode, read the same accessors off the result. What changes is the smoothing geometry. An areal field penalises differences between neighbours on a graph; a continuous field penalises roughness as a function of euclidean distance, with a range parameter that says how far the correlation reaches before it decays. NNGP and HSGP trade a little exactness for the speed needed on large coordinate sets, while the SPDE representation links a Matern field to a sparse precision through a mesh, which keeps the Gaussian-Markov advantages on continuous space. The choice among the three is mostly a question of sample size and how smooth you expect the surface to be.

The SPDE field has a dedicated fitter. fit_spde() takes the response, a design matrix, and the spatial_spde spec directly, builds the Matern precision on the mesh, and solves the field by sparse Laplace. Simulate a smooth Poisson surface on scattered coordinates and fit it with the range and marginal SD held fixed:

set.seed(20260531)
n      <- 300
coords <- data.frame(lon = runif(n), lat = runif(n))
field  <- 1.4 * (sin(2.5 * coords$lon) + cos(2.5 * coords$lat))
field  <- field - mean(field)
xcov   <- rnorm(n)
y      <- rpois(n, exp(1.0 + 0.5 * xcov + field))

spde <- spatial_spde(~ lon + lat, data = coords, max_edge = c(0.2, 0.5))
fit  <- fit_spde(y = y, X = model.matrix(~ xcov), spatial = spde,
                 family = "poisson", range = 0.4, sigma = 0.9)
round(fit$beta, 3)
#> [1] 0.988 0.540

The fixed-effect estimates land on the generating intercept and slope; the mesh-node field effects sit in fit$spatial_effects, ready to project onto a prediction grid. Leaving range and sigma at their default NULL switches fit_spde() to nested Laplace over the two hyperparameters and adds an outer Pareto-k-hat to the result (fit$pareto_k), the same accuracy diagnostic the areal nested integration reports.
